PA6340 Load Cell
The PA6340 Load Cell is an aluminium load cell designed for accurate platform and bench scale applications. It offers IP67 protection, C3 accuracy, and capacity options in both kilogram and pound ranges.
- Description
- Product Specifications
- Additional information
Description
he PA6340 Load Cell is suitable for compact weighing systems that need dependable performance, stable output, and strong environmental protection. It is available as the PA6340 and PA6340A, with recommended platform sizes of 300 × 300mm and 500 × 700mm respectively.
With a rated output of 2.0 mV/V, IP67 protection, aluminium construction, and 150% safe overload capacity, this load cell is well suited to platform scales, bench scales, packing systems, and general industrial weighing applications.
Key Features
- PA6340 and PA6340A options available
- Aluminium construction
- IP67 environmental protection
- C3 accuracy class
- Rated output of 2.0 mV/V
- Safe overload of 150% F.S
- Ultimate overload of 300% F.S
- 4-colour shielded cable included
- Suitable for compact platform scale applications
Applications
- Platform scales
- Bench scales
- Packing systems
- Industrial weighing systems
- Process weighing applications
| Model | Capacity Options | Recommended Max Platform Size | Material | Protection |
|---|---|---|---|---|
| PA6340 | 5, 10, 15, 20, 30, 50, 100, 150, 200 lb | 300 × 300 mm | Aluminium | IP67 |
| PA6340A | 5, 10, 15, 20, 25, 30, 50, 60, 100, 200 kg | 500 × 700 mm | Aluminium | IP67 |
Additional information
| Model | PA6340, PA6340A |
|---|
